· Excellent high and low temperature performance：Operates with natural cooling at ambient temperatures below 38°C, saving energy.
· Intelligent protection：Equipped with intelligent voltage, current, and temperature protection functions.
· Long service life：3000 cycles @ 0.5C, 80% DOD, at 25°C.
· Easy maintenance：Integrated BMS design, supports battery self-management, remaining energy, battery health management, and other functions.
· Anti-theft functionality：Compatible with various optional anti-theft features.
| Parameters/Model | CF48100T | CF48150T | ||
| Connection Method | 1P155 | 1P16S | 1P15S | 1P16S |
| Rated Energy | 4800Wh | 5120Wh | 7200Wh | 7680Wh |
| Rated Capacity | 100Ah | 100Ah | 150Ah | 150Ah |
| Rated Voltage | 48V | 51.2V | 48V | 48V |
| Voltage Range | 42~52.5V | 43.2~56.8V | 42~52.5V | 43.2~56.8V |
| Charging Current | 50A | 50A | 75A | 75A |
| Discharging Current | 100A | 100A | 150A | 150A |
| Operating Temperature | Charging:0~50°℃;Discharging:-20~55℃;Storage:-30~45℃ | |||
| Self-Discharge Rate | ≤3%(at 0~30℃ for 3 months) | |||
| Dimensions(W*D*H) | 440*420*130mm | 440*525*130mm | ||
| Weight | 41Kg | 43Kg | 56Kg | 60Kg |
| Communication Interface | RS485/RS232/CAN | |||
| Charging Current Limiting Function |
Automatically activates current-limited charging when detecting cell conditions such as low voltage,high voltage,low temperature,high temperature,poor consistency,or overcurrent protection during charging. |
|||
| Voltage Measurement Accuracy |
0~5V measurement range with accuracy≤10mV;0~60V measurement range with accuracy ≤0.5% | |||
| Current Measurement Accuracy |
Measurement accuracy≤1%(at 0.5C charge/discharge) | |||
| Anti-Theft Function | May support software-based anti-theft,communication-based anti-theft,gyroscope-based anti-theft,and other functionalities | |||
| Certifications | IEC62619、IEC62620、UL1973、UL9540A、UN38.3、ROHS、TLC、EMC | IEC62619、IEC62620、UL1973、UN38.3、 ROHS、EMC |
||
