· Temperature variation within the entire cabinet < 5°C
· optional cloud-edge collaboration,OTA upgrade
· High energy density, flexible layout, and expandability
· Modular prefabrication, no on-site installation required
| Parameters/Model | EnerGalactic-6261-0.5C | ||
| Battery Module | Cell Capacity | 588Ah-LFP | |
| Module Configuration | 1P104S | ||
| Module Nominal Voltage | 332.8V | ||
| Module Energy | 195.686kWh | ||
| Protection Level | IP67 | ||
| Battery Rack | Number of Modules | 4pcs | |
| Battery Rack Nominal Voltage | DC1331.2V | ||
| Voltage Range | 1144~1497.6V | ||
| Single Rack Energy | 782.745kWh | ||
| Battery Enclosure | Number of Battery Racks | 8pcs | |
| Battery System Energy | 6261kWh | ||
| Dimensions(W*D*H) | 6058*2438*2896mm | ||
| Weight | ≤45t | ||
| Cooling Method | Liquid Cooling | ||
| Protection Level | IP55 | ||
| Other Parameters | Compliance Standards | IEC62619、UL1973、UL9540A、UN38.3、UN3536 | |
