· Temperature variation within the entire cabinet < 3°C
· PACK-level fire protection for high safety
· High energy density, flexible layout, and expandability
· Modular prefabrication, no on-site installation required
| Parameters/Model | EnerGalactic-5015-0.5C | ||
| Battery Module | Cell Capacity | 314Ah-LFP | |
| Module Configuration | 1P52S | 1P104S | |
| Module Nominal Voltage | 166.4V | 332.8V | |
| Module Energy | 52.2496kWh | 104.499kWh | |
| Protection Level | IP67 | ||
| Battery Rack | Number of Modules | 8pcs | 4pcs |
| Battery Rack Nominal Voltage | DC1331.2V | ||
| Voltage Range | 1164.8~1476.8V | ||
| Single Rack Energy | 417.997kWh | ||
| Battery Enclosure | Number of Battery Racks | 12pcs | |
| Battery System Energy | 5015kWh | ||
| Dimensions(W*D*H) | 6058*2438*2896mm | ||
| Weight | ≤43t | ||
| Cooling Method | Liquid Cooling | ||
| Protection Level | IP54 | ||
| Other Parameters | Compliance Standards | IEC62619、IEC63056、UL1973、UL9540、UL9540A、UN38.3、UN3536、RoHS、 EN 61000-6-2、EN61000-6-4、EN62477-1 | |
