· Flexible Expansion, Multi-functional in One Unit, Adaptable to Various Application Scenarios
· Multiple Protection Systems
· Highly Integrated Design with AC/DC Integration
· Touchscreen Monitoring and Cloud-Based Maintenance
| Parameters/Model | PowerEco-130kW/261kWh | |
DC Side Parameters | DC Bus Maximum Voltage | 1000V |
| DC Side Maximum Current | 191A | |
| DC Voltage Operating Range | 650~1000V | |
| AC Grid-tied Parameters | Maximum Input Apparent Power | 140kVA |
| Maximum Input Active Power | 130kW | |
| Rated Input Voltage | 230/400V,3P+N+PE | |
| Maximum Continuous lnput Current | 206A | |
| Rated Input Frequency | 50/60Hz | |
| ACOff-grid Parameters | AC Off-grid Voltage | 230/400V,3P+N+PE |
| Maximum Continuous Output Current | 206A | |
| AC Off-grid Frequency | 50/60Hz | |
| Battery Parameters | Cell Capacity | 314Ah-LFP |
| Rated Energy | 261kWh | |
| Nominal Voltage | 832V | |
| Operating Voltage Range | 728~910V | |
| C-rate | ≤0.5C | |
| System level Parameters | HMI | 7-inch LCD Touch Screen |
| Fire Protection System | Perfluorohexanone Fire Extinguishing/Aerosol Fire Extinguishing | |
| Cooling Method | Liquid Cooling | |
| Grid-Off-grid switching time | 20ms | |
| Operating Temperature | -20~55℃ | |
| Protection Level | IP54 | |
| Dimensions(W*D*H) | <1100*1350*2350mm | |
| Weight | <2900Kg | |
| Other Parameters | Certifications | Cell:IEC62619,UL1973,UL9540A,UN38.3,RoHS,MSDS,Pack:UL9540A,UN38.3 |
